10-4
IM 05P03D21-01EN
10.3
Changing Current Output Range
Description
The analog output type can be selected from among 4 to 20, 0 to 20, 20 to 4, or 20 to 0
mA.
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange
Menusymbol
RET
.A
RET current output
range
STD
4-20: 4 to 20 mA,
0-20: 0 to 20 mA,
20-4: 20 to 4 mA,
20-0: 20 to 0 mA
OUT
Parameters and Corresponding T
erminals
RET
.A
RET terminal
78
80
