Contact Input/Output Functions
11
11.2.2 ChangingContactTypeofContactOutput
Description
The contact type can set the action direction of contact output assigned to the function.
SettingDetails
ContactOutputEquippedasStandard
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
AL1.D AL1 contact type PRO
0: When the event of assigned
function occurs, the contact
output is closed.
1: When the event of assigned
function occurs, the contact
output is opened.
ALM
AL2.D AL2 contact type PRO
AL3.D AL3 contact type PRO
AdditionalRelayContactOutput
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
AL4.D AL4 contact type PRO
0: When the event of assigned
function occurs, the NO
(normally open) terminal is
closed.
1: When the event of assigned
function occurs, the NC
(normally closed) terminal is
closed.
ALM
Additional Contact Output
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
DO1.D DO11 contact type PRO
0: When the event of assigned
function occurs, the contact
output is closed.
1: When the event of assigned
function occurs, the contact
output is opened.
DO
DO2.D DO12 contact type PRO
DO3.D DO13 contact type PRO
DO4.D DO14 contact type PRO
DO5.D DO15 contact type PRO
Refer to the table below for presence/absence of UM33A contact output.
Terminal area
Sufxcode:Type2
0 1 2 3
ALM4 (101-103) – AL4 AL4 AL4
E1-terminal area – – – DO11 to DO15
► Terminalarrangement:16.4Wiring
