YOKOGAWA UM33A User Manual

4-1
IM 05P03D21-01EN
Basic Operation
4
4.1 OverviewofDisplaySwitchandOperationKeys
The following shows the transition of Operation Display, Operation Parameter Setting
Display, and Setup Parameter Setting Display.
The “Operation Parameter Setting Display” has the parameters for setting the functions
necessary for the operation.
The “Setup Parameter Setting Display” has the parameters for setting the basic functions
of the indicator.
8 8 8
8 8 8 8 8
88
8 88 8
88
*1* Return to the Operation Display from
the Parameter Setting Display
Same as *1.
Press the key
for 3 seconds.
Press the keys
for 3 seconds.
+
AL Menu DisplayVER Menu DisplayCTL Menu Display
ALRM Menu Display
END DisplayEND Display
END DisplayEND Display END DisplayEND Display
press the keys
for 3 seconds
+
In the Setup Parameter Setting Display, In the Operation Parameter
Setting Display,
to move to the Operation Parameter Setting Display. to move to the Setup Parameter Setting Display.
press the keys
for 3 seconds
The Menu Display and Parameter Setting Display
are changed in a circular pattern.
The Menu Display and Parameter Setting Display
are changed in a circular pattern.
Operation Parameter Setting Display Setup Parameter Setting Display
Parameters for setting the basic
functions of the indicator
Parameters for setting the functions
necessary for the operation
• • • • • •
• • • • • • • • • • • •
PV Display
Power ON
SELECT Display-1 SELECT Display-5
Operation Display: See Chapter 6.
Operation Display
Chapter 4 Basic Operation
