8.1 Function Block Diagrams
Description
The Function block diagram describes only the basic functions.
Parameter symbols in the Function block diagram describe representative parameters.
For the functions and parameters which are not described in Function block diagram, see
the following.
► Contactinputassignment:11.1SettingContactInputFunction
► Contactoutputassignment:11.2SettingContactOutputFunction
► Analogoutputrangechange:10.3ChangingCurrentOutputRange
