3.4 BriefDescriptionofSettingDetails(Parameters)
This manual describes the Setting Details as follows in addition to the functional
Description.
SettingDetails
(DisplayExample)
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
A1 to A8
Alarm-1 to -8
setpoint
EASY
Set a display value of setpoint of
PV alarm, or velocity alarm.
-19999 to 30000 (Set a value
within the input range.)
Decimal point position depends on
the input type
AL
(1) Parameter symbol: Symbol displayed on Symbol display on the front panel.
(2) Name: Parameter name
(3) Display level: Indicates the parameter display level.
(4) Setting range: Parameter setting range
(5) Menu symbol: Indicates the menu to which the parameter belongs.
: Operation parameter
: Setup parameter
ParameterDisplayLevel
Displaylevel Description
EASY
Easy setting mode: The minimum
necessary parameters are displayed.
Corresponding parameters are displayed in
all modes.
STD
Standard setting mode: The wider
range of parameters than those
shown in Easy setting mode are
displayed.
Corresponding parameters are displayed only
in Standard setting mode and Professional
setting mode.
Parameter display level indicators "EASY"
and "PRO" are unlit in Standard setting
mode.
*: "STD" is the symbol used in this manual
only.
PRO
Professional setting mode: All
parameters are displayed.
Corresponding parameters are displayed only
in Professional setting mode.
Note
For more intelligible display operation of parameters and the references, see Chapter 17,
"Parameter Map."
