5.2 RestartingQuickSettingFunction
Once functions have been built using the Quick setting function, the Quick setting
function does not start even when the power is turned on. The following methods can be
used to restart the Quick setting function.
● SettheparameterQSM(Quicksettingmode)toONandturnonthepoweragain.
● SettheparameterIN(PVinputtype)toOFFandturnonthepoweragain.
CAUTION
The parameters related to the range or scale are initialized if the PV input type is
changed.
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
IN PV input type EASY OFF: Disable PV
QSM Quick setting mode EASY
OFF: Disable
ON: Enable
SYS
