YOKOGAWA UM33A User Manual

12-10
IM 05P03D21-01EN
12.1.13 SettingBrightnessAdjustmentofLCDandDisplayUpdateCycle
Description
ThebrightnessforPV,Setpoint,Bar-graph,andStatusindicatorcanbeadjusted.
Brightness ranges for each display can be set.
The LCD has a characteristic that the display action becomes late at the low temperature.
Thiscanbesolvedbyadjustingthedisplayupdatecycle(D.CYC).
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
BRI Brightness EASY (Dark) 1 to 5 (Bright)
DISP
B.PVW
White brightness
adjustmentofPV
display
PRO
Adjuststhewhitebrightness
of PV display.
(Dark) -4 to 4 (Bright)
B.PVR
Red brightness
adjustmentofPV
display
PRO
Adjuststheredbrightnessof
PV display.
(Dark) -4 to 4 (Bright)
BSP
Brightnessadjustment
of Setpoint display
PRO
AdjuststhebrightnessofSP
display.
(Dark) -4 to 4 (Bright)
B.STS
Brightnessadjustment
of Status indicator
PRO
Adjuststhebrightnessof
Status indicator.
(Dark) -4 to 4 (Bright)
D.CYC Display update cycle PRO
1: 100 ms
2: 200 ms
3: 500 ms
4: 1 s
5: 2 s
12.1SettingDisplayFunctions
