7.1.2 SettingBurnoutDetectionforInput
Description
The input value when input burnout occurs can be determined.
The input value is 105.0% of the input range when the upscale is set, and -5.0% of the
input range when the downscale is set.
Burnout detection is activated for TC, RTD, and standard signal (0.4–2 V, 1–5 V or 4-20
mA).
For standard signal, burnout is determined to have occurred if it is 0.1 V or less for the
range of 0.4–2 V and 1–5V, or if it is 0.4 mA or less for the range of 4–20 mA.
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
BSL PV input burnout action STD
OFF: Disable
UP: Upscale
DOWN: Downscale
PV
7.1SettingFunctionsofPVInput
