7-3
IM 05P03D21-01EN
Input (PV) Functions
7
(Continued)
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
SDP
(Scaling)
PV input scale decimal
point position
(for voltage / current
input)
EASY
0: No decimal place
1: One decimal place
2: Two decimal places
3: Three decimal places
4: Four decimal places
PV
SH
(Scaling)
Maximum value of PV
input scale
(for voltage / current
input)
EASY
-19999 to 30000, (SL<SH),
|SH-SL|≤30000
PV
SL
(Scaling)
Minimum value of PV
input scale
(for voltage / current
input)
EASY
-19999 to 30000, (SL<SH),
|SH-SL|≤30000
PV
When changing the PV decimal point position or the digit of the indicated value, can be
set by the following parameters.
Example: PV input type= K1 (-270.0 to 1370.0ºC), the digit is without decimal point for "0
to 1000ºC".
P.UNI=C
P.DP=0
P.RH=1000
P.RL=0
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
P.UNI Display PV input unit
STD
-: No unit
C: Degree Celsius
-: No unit
- -: No unit
- - -: No unit
F: Degree Fahrenheit
MPV
P.DP
Display PV input
decimal point position
0: No decimal place
1: One decimal place
2: Two decimal places
3: Three decimal places
4: Four decimal places
P.RH
Maximum value of
display PV input range
-19999 to 30000, (P.RL<P.RH),
|P.RH-P.RL|≤30000
P.RL
Minimum value of
display PV input range
7.1SettingFunctionsofPVInput
