17.1 Parameter Map
BriefDescriptionofParameterMap
GroupDisplay
"1 to 2" appearing in the parameter map are displayed on Group display (7 segments, 1
digit) while the parameter of PYS1 and PYS2 menu is displayed.
1: indicates the PYS1 parameter
2: indicates the PYS2 parameter
ParameterDisplayLevel
The marks below appearing next to the menu symbol and parameter symbol in the
parameter map indicate the display/non-display level.
Mark Display Displaylevel Description
None EASY
Easy setting mode: Displays
the minimum parameters.
Corresponding parameters are displayed
in all modes.
S
STD
Standard setting mode:
Displays a wider range of
parameters than displayed in
the Easy setting mode.
Corresponding parameters are displayed
only in Standard setting mode and
Professional setting mode.
Parameter display level indicators
"EASY" and "PRO" are unlit in Standard
setting mode.
*: "STD" is the symbol used in this
manual only.
P
PRO
Professional setting mode:
Displays all parameters.
Corresponding parameters are displayed
only in Professional setting mode.
Professional setting mode
Standard setting mode
Easy setting mode
► Displaylevel:12.3.2SettingParameterDisplayLevel
E1:
"E1" appearing in the parameter map indicates that the parameter is in E1-terminal area.
► E1: 16.4 Wiring (Terminal Block Diagram)
