YOKOGAWA UM33A User Manual

11-6
IM 05P03D21-01EN
KeyandDisplayStatus
The key and display status can be output to the contact output. (The setpoints below are
I relay numbers.)
Setpoint Function
Contact status
ON OFF
4705 PARA key
Key is pressed Key is not pressed
4706 DISP key
4707 Right arrow key
4708 Down arrow key
4709 SET/ENTER key
4710 Up arrow key
4711 Left key
4715 Fn key
OperationModeandStatus
Setpoint Function
Contact status
ON OFF
4256 FAIL output Normal status FAIL status
SystemErrorStatus
Setpoint Function
Contact status
ON OFF
4769 Message display interruption 1 status With interruption Without interruption
4770 Message display interruption 2 status With interruption Without interruption
4771 Message display interruption 3 status With interruption Without interruption
4773 Message display interruption 4 status With interruption Without interruption
5457 Power ON →Initializationstatus During operation Initializing the system
ErrorStatus
Setpoint Function
Contact status
ON OFF
4065 PV input ADC error
Error occurs Normal
4073 PV input burnout error
4070 PV input RJC error
4097 PV input burnout error
4101 PV input over-scale
4102 PV input under-scale
SystemErrorStatus
Setpoint Function
Contact status
ON OFF
4001 System data error
Error occurs Normal
4002 Calibration value error
4003 User (parameter) default value error
4005 Setup parameter error
4006 Operation parameter error
4009 Faulty FRAM
11.2SettingContactOutputFunction
