11-5
IM 05P03D21-01EN
Contact Input/Output Functions
11
AlarmStatus
The alarm status can be output to the contact output. (The setpoints below are I relay
numbers.)
► Irelay:UTAdvancedSeriesCommunicationInterface(RS-485,Ethernet)User'sManual
Setpoint
Function
Alarm status
Alarm output
status
4321 4353 Alarm 1
4322 4354 Alarm 2
4323 4355 Alarm 3
4325 4357 Alarm 4
4326 4358 Alarm 5
4327 4359 Alarm 6
4329 4361 Alarm 7
4330 4362 Alarm 8
• Alarm status: The internal alarm status is turned on when an alarm occurs and
turned off in normal condition
• Alarm output status: Contact output status when an alarm occurs (ON in alarm
condition and OFF in normal condition)
However, the output status depends on the settings of energized/de-energized of alarm,
latch action, and contact type.
The above assumes that the contact type is energized. (Then contact is turned on when
an event occurs.)
To output the normal alarm to the contact output, assign the alarm output status.
► Alarm action: 9.1 Setting Alarm Type
AlarmLatchStatus
The alarm latch status can be output to another contact output irrespective of the setting
of alarm-1 to -8 type (AL1 to AL8). (The setpoints below are I relay numbers.)
► I relay: UTAdvanced Series Communication Interface (RS-485, Ethernet) User's Manual
Setpoint
Function
Alarm output
latch 1 status
Alarm output
latch 2 status
Alarm output
latch 3 status
Alarm output
latch 4 status
4385 4417 4449 4481 Alarm 1
4386 4418 4450 4482 Alarm 2
4387 4419 4451 4483 Alarm 3
4389 4421 4453 4485 Alarm 4
4390 4422 4454 4486 Alarm 5
4391 4423 4455 4487 Alarm 6
4393 4425 4457 4489 Alarm 7
4394 4426 4458 4490 Alarm 8
• Alarm output latch 1, 2, 3, and 4 status: ON in the latch status of the contact output
when an alarm occurs and OFF in the latch release status of the contact output in
normal condition
However, the output status depends on the settings of contact type.
► Alarm latch action: 9.1 Setting Alarm Type
11.2SettingContactOutputFunction
