Retransmission Output Functions
10
SettingDetails
Parameter
symbol
Name Displaylevel Settingrange Menusymbol
A1 to A11
10-segment
linearizer
input
PRO
Output linearizer: -5.0 to
105.0%
PYS2
B1 to B11
10-segment
linearizer
output
PRO
Output linearizer: -5.0 to
105.0%
PMD
10-segment
linearizer
mode
PRO
0: 10-segment linearizer
bias
1: 10-segment linearizer
approximation
Note1: The group number 2 is displayed on Group display while each parameter is displayed.
Set it in the following orders.
(1) The RET analog output is set by the parameter in PYS2 menu.
Setpoint RET functions before output to RET terminal.
(2) PMD: Specifies whether to use it as a 10-segment linearizer bias or a 10-segment
linearizer approximation.
(3) A1 to A11, B1 to B11: Sets the 10-segment linearizer input and 10-segment linearizer
output.
Note
• Set the 10-segment linearizer so that it increases monotonically.
