YOKOGAWA UM33A User Manual

3
All Rights Reserved. Copyright © 2010, Yokogawa Electric Corporation
GS 05P03D21-01EN Mar.14,2016-00
nHardwareSpecications
DisplaySpecications
• PV display: 5-digit, 14-segment active color LCD (white/red)
Character height: 14.2 mm
• Data display: 5-digit, 11-segment color LCD (orange)
• Bar graph display: 12-segment color LCD (orange)
8
(1) PV display
(2) Group display
(8) Security indicator
(4) Data display
(3) Symbol display
(5) Event indicator
(6) Key navigation indicator
(7) Parameter display level
indicator
Names of Display Parts
8
(4) Light-loader interface
(5) User function keys
(1) DISP key
(2) PARA key
(3) SET/ENTER key
Up/Down/Left/Right arrow keys
