Zebra TC20

Accessories
32
Figure 25 Secure Screw
9. Insert the Ethernet Module into the bracket.
Figure 26 Insert Module
10.Push module in until it is seated properly. The USB micro-B connector on the Ethernet module plugs into
the USB micro-AB port on the cradle.
USB micro-AB Port
