Zebra TC20

Accessories
46
Figure 46 Horizontal Mounting Template
3. Align the mounting bracket’s bottom mounting key holes with the screws.
4. Hang the bracket on the screws.
Figure 47 Horizontal Installation
5. Install two top screws.
6. Tighten all screws.
