Zebra ZE500 User Manual

Troubleshooting
Error Messages
126
P1051584-002 8/23/12
There is not enough memory to
perform the function specified on
the second line of the error
message.
Free up some of the print engine’s
memory by adjusting the label format
or print engine parameters. One way to
free up memory is to adjust the print
width to the actual width of the label
instead of leaving the print width set to
the default. See
Print Width
on page 77.
Ensure that the device, such as a
FLASH memory card, is installed and
not write protected or full.
Ensure that the data is not directed to a
device that is not installed or is
unavailable.
Call a service technician.
Table 15 • Error Messages (Continued)
Display/
Print Engine Condition
Possible Cause Recommended Solution

Zebra ZE500 Specifications

General

Print technology	-
Maximum resolution	300 x 300 DPI
Maximum printing width	168 mm
Wi-Fi	No
Ethernet LAN	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Parallel ports quantity	1
Flash memory	64 MB
Internal memory	16 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 129-Auto, Code 39, Code 49, Code 93, EAN13, EAN8, Industrial 2/5, Interleaved 2/5, MaxiCode, PDF417, POSTNET, QR Code, TLC39, UPC-A, UPC-E
Processor frequency	133 MHz
Page description languages	XML, ZPL, ZPL II
Display	LCD
Product color	Black
Housing material	Metal
Core diameter	25.4 mm
Ribbon length	600 m
Maximum label width	180 mm
Maximum media length	3810 mm
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-40 - 71 °C
Operating temperature (T-T)	32 - 104 °F
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 85 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	438 mm
Width	245 mm
Height	300 mm
Weight	17300 g
