Introduction
Control Panel Display
26
P1051584-002 8/23/12
View the Non-Resettable Counter
This parameter displays the total length of media that the printer
has printed.
See Non-Resettable Counter on page 83 for more information.
View User-Controlled Counter 1
This parameter displays the total length of media that the printer
has printed since this counter was last reset.
See User-Controlled Counters on page 83 for more information.
View User-Controlled Counter 2
This parameter displays the total length of media that the printer
has printed since this counter was last reset.
See User-Controlled Counters on page 83 for more information.
Print Counter Readings
Prints a label that lists the odometer readings for the following:
the non-resettable counter
the two user-controlled counters
the Early Warning for Maintenance counters, which indicate
when the printhead was last cleaned and the printhead life (If
the Early Warning for Maintenance feature is disabled, the
counters related to it do not print.)
See Print Counter Readings on page 83 for more information.
Print Font List
This option prints a label that lists the available fonts in the print
engine, including standard print engine fonts plus any optional
fonts. Fonts may be stored in RAM or Flash memory.
See Print Information on page 84 for more information.
