Zebra ZE500 - Page 67

67
Printer Setup and Operation
Load Ribbon and Media
8/23/12 P1051584-002
12. Slide in the media guide until it just touches the edge of the media.
13. Press down on the pinch roller assembly until it locks closed.
14. Rotate the printhead-release latch to the closed position.
LH RH
LH RH
LH RH
