Printer Setup and Operation
Load Ribbon and Media
68
P1051584-002 8/23/12
15. Raise the peel roller latch so that the peel roller assembly pivots downward.
16. Thread the liner around the peel bar, under the platen roller, and through the peel roller
assembly.
Important • If the applicator has an air tube, route the liner between the air tube and the
peel bar. Do not thread the liner over the air tube.
