Printer Configuration and Adjustment
Changing Printer Settings
98
P1051584-002 8/23/12
Host Handshake Set the Host Handshake Protocol Value
Select the handshake protocol that matches the one being used by the host computer.
Accepted values:
• XON/XOFF
• RTS/CTS
• DSR/DTR
Related ZPL command(s):
^SC
SGD command used:
none
Control panel menu item: HOST HANDSHAKE on page 30
Printer web page:
View and Modify Printer Settings >
Serial
Communications Setup >
Host
Handshake
Protocol Protocol is a type of error checking system. Depending on the selection, an indicator
may be sent from the print engine to the host computer signifying that data has been
received. Select the protocol that is requested by the host computer.
Accepted values:
• NONE
• ZEBRA
• ACK_NAK
Note • ZEBRA is the same as ACK_NAK,
except that ZEBRA response messages are
sequenced. If
ZEBRA is selected, the print
engine must use
DSR/DTR for host
handshake protocol.
Related ZPL command(s):
^SC
SGD command used: none
Control panel menu item:
PROTOCOL on page 30
Printer web page:
View and Modify Printer Settings >
Serial
Communications Setup > Protocol
Network ID This parameter assigns a unique number to the print engine when the print engine is
operating in an RS422/485 multi-drop network environment (an external RS422/485
adapter is required). This gives the host computer the means to address a specific print
engine. This does not affect TCP/IP or IPX networks. Set a unique network ID number
for this print engine.
Accepted values:
000 to 999
Related ZPL command(s):
^NI
SGD command used: none
Control panel menu item:
NETWORK ID on page 30
Printer web page:
View and Modify Printer Settings >
Serial
Communications Setup > Network ID
Table 11 • Port Settings (Continued)
