Zenith XBR413 - Page 84

3-109
F
Execute “E.ALPC Test for AS”of “How
to Test Tool”(Select “DVD-R Rec
Mode”and trigger)
Check the input of LDEN-DVD.
(pin 17 of CN101 : ‘H’)
Check the input of VWDC.
(pin 28 of CN101)
Check the input of recording pulse.
(pin 31,32 of CN101)
Check the input of FPD.
(pin 19 of CN101)
END
G
Execute “E.ALPC Test for AS”of “How
to Test Tool”(Select “DVD-RW Rec
Mode”and trigger)
Check the input of LDEN-DVD.
(pin 17 of CN101 : ‘H’)
Check the input of VWDC.
(pin 29 of CN101)
Check the input of recording pulse.
(pin 31,32 of CN101)
Check the input of FPD.
(pin 19 of CN101)
END
