Note: For the security of the device, it is recommended to register a super
administrator the first time you use the device.
 The punch state options can also be displayed and used directly on the
standby interface. Tap anywhere on the screen apart from the icons, and
six shortcut keys appears on the screen, as shown in the figure below:
 Press the corresponding punch state key to select your current punch
state, which is displayed in green. Please refer to "Shortcut Key Mappings"
for the specific operation method.
Note: The punch state options are off by default and need to select other mode
options in the "Punch State Option" to get the punch state options on the
standby screen.

ZKTeco SpeedFace-V3L Specifications

General

Display type	LCD
Screen shape	Flat
Built-in display	Yes
Display diagonal	2.4 \
Display size (HxV)	240 x 320 mm
Internal memory	256 GB
Processor cores	2
Internal storage capacity	512 GB
Operating system installed	Linux
Type	Face recognition terminal
Access code reader	-
Authentication type	Biometric, Face recognition
Access chip/card reader	No
Face recognition distance	0.5 - 2 m
False Rejection Rate (FRR)	0.02 %
False Acceptance Rate (FAR)	0.01 %
International Protection (IP) code	IP65
Operating temperature (T-T)	-5 - 45 °C
Total megapixels	1 MP
RS-485 ports	1
Package weight	800 g

Weight and Dimensions

Depth	58.5 mm
Width	185 mm
Height	20 mm
Weight	300 g
