Setting up the light curtain
78
10.2.2 Switching on the integrated laser alignment system (ILAS)
Note:
The laser alignment system automatically switches itself off after five minutes.
Caution:
Class 2 laser
Possible eye damage.
• Do not look into the laser beam.
• Switch off the laser alignment system when not in use.
A Approach the laser alignment system control panel (on the receiver at the top, on the light barrier
transmitter at the bottom).
B Briefly place your finger or hand on the finger symbol.
Results
The laser alignment system of the pillar pair will switch to a highly visible flashing light.
