Chapter 1 Introducing the VDSL Router
Basic Home Station VDSL2 P8701T User’s Guide
17
3 Enable WPS on another WPS-enabled client device within range of the VDSL Router. If you do not
know how to enable WPS on that client device, refer to its manual. The Wifi LED flashes green and
orange while the VDSL Router sets up a WPS connection with the other WPS enabled client device.
4 Once the connection is successfully made, the Wifi LED shines green.
To turn off the wireless network, press the Wifi/WPS button on the front of the VDSL Router for
one to five seconds. The Wifi LED turns off when the wireless network is off.
1.7 Wall-mounting Instructions
Complete the following steps to hang your VDSL Router on a wall.
Figure 3 Wall-mounting Example
1 Select a position free
of obstructions on a sturdy wall.
2 Drill two holes for the screws.
Be careful to avoid damaging pipes or cables located inside the wall
when drilling holes for the screws.
3 Do not insert the screws all the way into the wall. Leave a small gap of about 0.5 cm between the
heads of the screws and the wall.
4 Make sure the screws are snugly fastened to the wall. They need to hold the weight of the VDSL
Router with the connection cables.
5 Align the holes on the back of the VDSL Router with the screws on the wall. Hang the VDSL Router
on the screws.
