Chapter 2 User Setup Guide
Basic Home Station VDSL2 P8701T User’s Guide
30
2.7 Setting Up a NAT Virtual Server for a Game Server
This examples configures a virtual server to forward traffic from Civilization IV players on the
Internet (A in the figure below) to a server on a computer behind the VDSL Router.
Note: If firewall is enabled, you may also need to configure a firewall rule for the relevant
ports. See Section 2.9.2 on page 35.
Tutorial: NAT Port Forwarding Setup
Thomas configures virtual servers to forward TCP and UDP port 6500, and UDP ports 2302 and
13139 traffic to port 6500 at the server’s IP address of 192.168.1.34.
1 Click the Network map screen’s ? 192.168.1.34 link.
2 Specify a name (CivIV in this example) and type (Desktop here). Click Configure applications
and ports.
D=192.168.1.34
WAN
LAN
TCP/UDP port 6500
A
UDP ports 2302 and 13139
To Next Page
