ZyXEL Communications P8701T User Manual

Chapter 4 WAN
Basic Home Station VDSL2 P8701T User’s Guide
94
4.4.1.7 Configuration Summary
This read-only screen shows the current WAN connection settings.
Figure 30 WAN Configuration: Configuration Summary
The following table describes the labels in this screen.
Available WAN
Interfaces
These are the WAN interfaces you can select from.
Use the following
Static DNS IP
address
Select this to have the VDSL Router use the DNS server addresses you configure
manually.
Primary DNS
server
Enter the first DNS server address assigned by the ISP.
Secondary DNS
server
Enter the second DNS server address assigned by the ISP.
Obtain IPv6 DNS
info from a WAN
interface
Select this to have the VDSL Router get the IPv6 DNS server addresses from the ISP
automatically.
WAN Interface
selected
Select a WAN interface through which you want to obtain the IPv6 DNS related
information.
Use the following
Static IPv6 DNS
address
Select this to have the VDSL Router use the IPv6 DNS server addresses you configure
manually.
Primary IPv6
DNS server
Enter the first IPv6 DNS server address assigned by the ISP.
Secondary IPv6
DNS server
Enter the second IPv6 DNS server address assigned by the ISP.
Back Click this button to return to the previous screen.
Next Click this button to continue.
Table 25 WAN Configuration: DNS Server: PPPoE or IPoE
LABEL DESCRIPTION
Table 26 WAN Configuration: Configuration Summary
LABEL DESCRIPTION
Connection Type This is the encapsulation method used by this connection.
NAT This shows whether NAT is active or not for this connection.
Full Cone NAT This shows whether full cone NAT is active or not for this connection.
IGMP Multicast This shows whether IGMP multicasting is active or not for this connection.
Quality Of Service This shows whether QoS is active or not for this connection.
