Chapter 5 LAN Setup
Basic Home Station VDSL2 P8701T User’s Guide
106
5.2.1 Add DHCP Static IP Lease Screen
Click Add Entries in the LAN Setup screen to display the following screen.
Enable IGMP Snooping Enable IGMP snooping to have the VDSL Router passively learn memberships in
multicast groups.
Select Standard Mode to have the VDSL Router forward multicast packets to a port
that joins the multicast group and broadcast unknown multicast packets from the
WAN to all LAN ports.
Select Blocking Mode to have the VDSL Router block all unknown multicast
packets from the WAN.
Disable DHCP Server Select this to have the VDSL Router not provide DHCP services. Users must
configure LAN devices with manual network settings if you do not have another
DHCP server on the network.
Enable DHCP Server Select this to have the VDSL Router serve as the DHCP server for the network to
assign IP addresses and provide subnet mask, gateway, and DNS server information
to LAN devices.
Start IP Address This field specifies the first of the contiguous addresses in the IP address pool.
End IP Address This field specifies the last of the contiguous addresses in the IP address pool.
DHCP Server Lease
Time
Specify for how many hours to assign an IP address to a LAN device before making
it available for reassignment to other systems.
Static IP Lease List Use this table to assign IP addresses on the LAN to specific computers based on
their MAC Addresses.
MAC Address The MAC (Media Access Control) of a LAN device to which the entry’s IP address is
assigned.
IP Address This field displays the IP address reserved for the LAN device with the entry’s MAC.
Remove Select entries and click the Remove Entries button to delete them.
Add Entries Click this button to create a new static IP lease entry.
Obtain DNS info from
WAN
Select this to have the VDSL Router get the Domain Name System (DNS) server
addresses from the VDSL Router’s WAN interface.
Use Static DNS IP
address
Select this to have the VDSL Router use the DNS server addresses you configure
manually.
First DNS Server,
Second DNS Server
Enter the first and second DNS (Domain Name System) server IP address the VDSL
Router passes to the DHCP clients.
Configure the second IP
Address and Subnet
Mask for LAN interface
Select the check box to use IP alias to configure another LAN network for the VDSL
Router.
IP alias partitions a physical network into different logical networks over the same
Ethernet interface. The VDSL Router supports multiple logical LAN interfaces via its
physical Ethernet interface with the VDSL Router itself as the gateway for the LAN
network. You can also configure firewall rules to control access to the LAN's logical
network (subnet).
IP Address Enter the second LAN IP address of your VDSL Router in dotted decimal notation.
Subnet Mask Type the subnet mask of your network in dotted decimal notation, for example
255.255.255.0 (factory default).
Apply/Save
Click this button to save your changes.
Table 28 LAN Setup (continued)
LABEL DESCRIPTION
