3D Systems, Inc.
29
INSTALL PRINT PLATFORM
1. Clean platform using Isopropyl Alcohol before installing into printer.
2. Open the chamber door.
3. Align platform’s rear notch into x-carriage’s locating tab at the back of carriage (A).
4. Align platform’s front notch (B) front locating tab.
5. Slide the latch release back and insert latch’s tab into the print platform’s front notch.
6. Release latch to secure print platform.
7. Close the front door and press “Play” on operator’s panel to bring the printer ONLINE (C).
8. To remove the platform, push latch back and lift platform from x-carriage.
A
B
C
