3D Systems, Inc.
62
STATUS AND MESSAGE LINES (CONT’D)
MESSAGE CAUSE ACTION
PRE-JOB CHECKS • Briey displayed during printer build preparation None.
BUILDING • The printer is currently building. Allow the build job to continue or
press PAUSE or STOP to stop
building.
RAISING PRINTHEAD • The printer is raising the printhead so you can
remove the platform.
None. (This occurs automatically
before every build.)
REMOVE BUILD • The chamber door is open. Remove the platform and replace
it with a clean platform. Refer to
removal of build platform.
SHUTDOWN IN PROGRESS • You selected the SHUTDOWN MODELER menu
option, then pressed YES twice. The printer is
cooling down so power can be switched off. Refer
to printer shutdown.
None. DO NOT switch off the printer
while shutdown is in progress.
SHUTDOWN COMPLETE • Printer cool down is complete; printer is ready for
power off.
Wait for OK TO POWER OFF
message, then switch power off at the
printer’s rear panel.
STANDBY • The printer is in energy-saver mode. All internal
subsystems are partially cooled and the printer is
inactive.
None. The printer will warm to
operating temperature when you
press any button or submit a build job.
WAITING FOR JOB • The printer is online, but there is no build job in it’s
queue. The printer is ready to build as soon as it
receives a job.
Submit a build job to the printer. Refer
to submit a build job.
WARMING STAGE [4,3,2,1] • The material heaters and printhead jet heaters
gradually warm up to either standby or build tem-
perature.
None. The numbers on the
Operator’s Panel displays the count
down as the printer warms up.
At Warming Stage 1, all heaters and
material are at build temperature.
