3D Systems ProX DMP 300 - 4 Prox Dmp 300 at a Glance; DMP 300 System Components

253D SYSTEMS, INC. PN:80-D27 Rev.B
4
PROX® DMP 300 AT A GLANCE
PROX
®
DMP 300 SYSTEM COMPONENTS
A
CHAMBER DOOR (SEE SECTION "A. CHAMBER DOOR" ON PAGE 26)
B
MANUFACTURTING CHAMBER (SEE SECTION "B. MANUFACTURING CHAMBER" ON PAGE 26)
C
POWDER RECYCLING (SEE SECTION "C. POWDER RECYCLING" ON PAGE 29)
D
CONTROL PANEL AND EXTERNAL CONTROL (SEE SECTION "D. CONTROL PANEL AND EXTERNAL CONTROL
PANEL" ON PAGE 31)
E
STACK LIGHT (SEE SECTION "E. STACK LIGHT" ON PAGE 32)
F
LASER ASSEMBLY (SEE SECTION "F. LASER ASSEMBLY" ON PAGE 32)
G
CONTROL CABINET (BEHIND THE MACHINE) (SEE SECTION "G. CONTROL CABINET" ON PAGE 33)
H
SUPPLY CABINET (BEHIND THE MACHINE) (SEE SECTION "H. SUPPLY CABINET" ON PAGE 33)
I
AIRLOCK (SEE SECTION "I. AIRLOCK" ON PAGE 34)
J
EXTERNAL PROCESS FILTER ASSEMBLY* (SEE SECTION "J. EXTERNAL FILTER ASSEMBLY" ON PAGE 35)
B
I
HG
F
C
D
J
E
A
