373D SYSTEMS, INC. PN:80-D27 Rev.B
POWERING UP THE PRINTER
1. Make sure that the 32A circuit-breaker is engaged upstream of the machine.
2. Turn on the main switch on the connection panel of the supply cabinet(1).
3. Switch on the UPS (see section "H. Supply cabinet" on page 33).
4. Make sure that all doors are closed and emergency stops are not pushed.
5. Switch the locking key to position “1”, on the external controls panel (2).
6. Open the gas valve (3) and compressed air valve (4).
7. Start the machine by pressing the start push button, on the external controls panel (5).
8. The PX Control application will automatically start and be displayed on the control panel.
To launch the PX Control application manually, double-click on the icon “PX_Control” from the desktop.
1
3
4
2
5
To Next Page
