Pannoramic 250 1.15 User’s Guide 1 Product Description
Objectives
Figure 5 – Objective changer
You can select two different objectives to be equipped with the Pannoramic 250, the first objective
(1) and the second objective (2).
20x/NA 0.80 and 40x/NA 0.95 objectives can be used (the 40x objective cannot be used in Brightfield
mode, but only in Fluorescent). You can change between the objectives with one click. This helps you
to select the magnification and resolution that is the most suitable for your requirements.
Important!
Note, that higher resolution results in slower digitization process.
March 13, 2012 – Rev. 1 3DHISTECH Ltd. 19(135)
