Pannoramic 250 1.15 User’s Guide 4 Software Description
Functions
• To move the lowest magazine in the input stack to the loading position click .
• To move the magazine into the output stack, click .
• To move a selected slide from its magazine to the specimen holder either enter its position
number to the Current slide field and click .
• To return the slide to its magazine, click .
• To move all magazines to the output stack, click .
To display an image of the barcode area, click . You can redefine the barcode reading
area by dragging the edges of the green square.
To check whether the barcode reading settings are correct, display the barcode digits in the Barcode
field by clicking .
Note:
If you did not set the barcode type correctly, or there is no barcode in
the barcode area, the software will display the following error
message: “Barcode recognition unsuccessful! There might be no
barcode present.”
1D Barcode Types
You can select the following 1D barcode types:
• Code 128
• Code 93
• EAN 8
• EAN 13
• UPC-A
March 13, 2012 – Rev. 1 3DHISTECH Ltd.
37(135)
