Pannoramic 250 1.15 User’s Guide 4 Software Description
2D Barcode Types
You can select the following 2D barcode types:
• Data Matrix
• PDF417
• MicroPDF417
• Maxicode
• QR code
1D barcodes with check digit (CDV)
You can select the following 1D barcodes with check digit (CDV):
• Code 39
• Interleaved 2 of 5
The check digit is always the last digit of the barcode. It is an additional checking number.
If you select Exclude check digit, then the check digit number will also be analyzed as a barcode
number.
Foreground Color
You can select the following foreground color of the barcode area:
• Black
• White
Barcode Image Compensation
Click Use barcode compensation image to use the previously created compensation image for
scanning the label area. You can take a new compensation image from a slide with blank barcode
sticker by clicking . You need a slide with a label area covered fully by a white sticker.
The compensation image improves the effectiveness of barcode reading.
March 13, 2012 – Rev. 1 3DHISTECH Ltd.
38(135)
