Pannoramic 250 1.15 User’s Guide 4 Software Description
Note:
You can separate the character groups with any character you choose,
it will not be read by the software.
Example for barcode usage
• Barcode: Folder_Vir_123_prof_n
• Folder is the folder for saving
• Vir is the name of the virtual slide
• 123_prof_n is the profile name
• The barcode control will then look like the following:
• Folder mask 1: 1-6
• Folder mask 2: <empty>
• Folder mask 3: <empty>
• Folder mask 4: <empty>
• Folder mask 5: <empty>
• Name mask: 8-10
• Profile mask: 12-21
Note:
The Profile mask row is inactive if the option Apply one profile to all
slides is active.
4. Generate name if no name was defined.
By choosing this option, a name is generated automatically in the following format if no
name was defined and there is no barcode:
<magazine number>M<slide position> (for example, 1M10)
