PBX Networking
169
Tip: If, for example, you are configuring a route which can be seized
using routing code “5” and have selected one or more bundles
for this route, change the Prefix for dest. call number at incom-
ing internal setting to “5” for this bundle in order to enable the
route to be reseized.
Owing to their hardware properties, not all S
0
ports of the OpenCom 100 can be used
for PBX networking without restrictions. Depending on the type of system, some
ports can only operate in the L1 master mode or L1 slave mode. The external S
0
and
S
2M
ports can be set according to the following table.
Legend
S = Slave
M/S = Master/Slave
Note
The S
0
ports on add-on cards can be operated in both L1 master and L1 slave mode.
S
0
1 S
0
2 S
0
3 S
0
4 S
2M
OpenCom 130 S M/S - - M/S
OpenCom150----M/S
