Factory Settings on Delivery
17
Factory Settings on Delivery
The following basic settings and features are active on delivery. We recommend that
you configure the OpenCom 100 communications system to suit your individual
requirements before using it (see Configuration starting on page 79).
The factory settings apply to smallest version of the OpenCom 131 and OpenCom 130
(which only features the basic module). If an expansion module with interface cards
exists, the additional interfaces are initially unconfigured. You must therefore first
configure the slots of the expansion module to commission the interfaces.
Note
The OpenCom 150 generally requires the slots to be configured before any interface
can be commissioned.
Telephony Basic Settings
OpenCom 130
• The S
0
1 port is configured as a multi-terminal connection, and the S
0
2 port as a
system port.
• Aastra 677x system telephones with the telephone numbers 30 to 32 are con-
figured on the three U
pn
ports.
• Analogue terminals with the telephone numbers 10 to 13 are configured on the
four a/b ports.
OpenCom 131
• The S
0
1 port is configured as a multi-terminal connection, and the S
0
2 port as a
system port.
• Aastra 677x system telephones with the telephone numbers 30 to 32 are con-
figured on the three U
pn
ports.
• Analogue terminals with the telephone numbers 10 to 17 are configured on the
eight a/b ports.
