Mounting the OpenCom 150 Rack InfoCom System
76
Technical Data
(differences to the wall-mounted OpenCom 150 only)
Dimensions:
• Width: 19-inch panel with flange for mounting in installation cabinet
• Height: 3U
• Depth: approx. 340 mm
Weight:
approx. 7.8 kg
Connection of 230 VAC power supply on rear side via inlet connector for non-heating
apparatus
Connection of all ports via RJ 45 jacks on front panel
Note
The ISDN S
0
ports on the front panel may only be switched in one direction (internal
or external). Use of the external port with a crossover (Rx-Tx) patch cable in parallel to
the S
0
internal port (for two S
0
terminals on the same bus) may severely limit the
range of the S
0
bus.
