Installation
38
• The slots are not of the same type. Therefore some of the available interface cards
may not be operated in all slots. Note the overview under Interface Cards starting
on page 47.
OpenCom 130: Installing an interface card in an expansion module slot
Proceed as described below to install an interface card:
1. Turn off the OpenCom 100. Open the housing cover.
2. Remove the slot card from the transport packaging. Check that it is the correct slot
card type. There is a sticker with the type name on the connector.
CAUTION!
Static charges can damage electronic components. Pay attention
to the regulations regarding the handling of electrostatically
sensitive components.
Type (name) of
interface card
