Program Interface Library AR_SET_CONFIG
CEI-100/CEI-200/CEI-x20 User’s Manual 133
ARU_DAC_VALUE_01 – set DAC value (non-220/420 only).
ARU_DAC_VALUE_16
ARU_OUTPUT_LEVEL_ADJ_01 – enable/disable variable transmitter
ARU_OUTPUT_LEVEL_ADJ_32 voltage (520/520A/620 only).
ARU_DISCRETE_OUTPUTS set value of discrete outputs.
ARU_TX_CH01_HB_INJ – high-bit injection on/off.
ARU_TX_CH32_HB_INJ
ARU_TX_CH01_LB_INJ – low-bit injection on/off.
ARU_TX_CH32_LB_INJ
ARU_TX_CH01_GAP_INJ – transmit short gap enabled or
ARU_TX_CH32_GAP_INJ disabled.
ARU_RX_CH01_AWAIT_DATA – enable/disable receiver ‘await data’
ARU_RX_CH32_AWAIT_DATA mode.
value (input) value to set the item:
CEI-100/200/x20 Values
If the requested item is, ARU_Xn_RATE or ARU_Rn_RATE (where
“n” is the transmitter number or receiver pair number), then valid
values are:
AR_HIGH high rate (100Kbs, 50Kbs for a CSDB
channel).
AR_LOW low rate (12.5Kbs).
If the requested item is ARU_RnXm_PARITY (where “n” is the
receiver pair number and “m” is the transmitter number), then valid
values are:
AR_ODD odd parity.
AR_EVEN even parity.
See AR_SET_RAW_MODE for information about disabling parity.
If the requested item is ARU_INTERNAL_WRAP, then valid values
are:
AR_WRAP_ON internal wrap enabled
AR_WRAP_OFF internal wrap disabled
For the CEI-100/200, internal wrap mode causes the transmit channel to
be internally connected to the two receive channels. Transmit data is
received as transmitted on the first channel. It is received as the one's
complement on the second channel.
