Installation Configuring the CEI-520 and CEI-520A
CEI-100/CEI-200/CEI-x20 User’s Manual 18
Table 11. Front View – Standard CEI-520/520A ARINC 429 I/O Connector (P2)
Pin
Signal
Pin
Signal
Pin
Signal
Pin
Signal
1
TX1+
35
TX1-
18
RX1+
52
RX1-
2
TX2+
36
TX2-
19
RX2+
53
RX2-
3
TX3+
37
TX3-
20
RX3+
54
RX3-
4
TX4+
38
TX4-
21
RX4+
55
RX4-
5
TX5+
39
TX5-
22
RX5+
56
RX5-
6
TX6+
40
TX6-
23
RX6+
57
RX6-
7
TX7+
41
TX7-
24
RX7+
58
RX7-
8
TX8+
42
TX8-
25
RX8+
59
RX8-
9
TX9+
43
TX9-
26
GND
60
GND
10
TX10+
44
TX10-
27
RX9+
61
RX9-
11
TX11+
45
TX11-
28
RX10+
62
RX10-
12
TX12+
46
TX12-
29
RX11+
63
RX11-
13
TX13+
47
TX13-
30
RX12+
64
RX12-
14
TX14+
48
TX14-
31
RX13+
65
RX13-
15
TX15+
49
TX15-
32
RX14+
66
RX14-
16
TX16+
50
TX16-
33
RX15+
67
RX15-
17
GND
51
GND
34
RX16+
68
RX16-
For external wrap, connect each transmit signal to the corresponding
receive signal (e.g. TX1+ to RX1+, TX1- to RX1-, etc.).
Also available are the CEI-520-1208-C/CEI-520A-1208-C (which provide
CSDB support) and the CEI-520-xxxx-J/CEI-520A-xxxx-J (which provide
ARINC 573/717 support). The P2 connector pinouts for these
configurations are shown in the following tables.
Table 12. Front View – CEI-520-1208-C/CEI-520A-1208-C I/O Connector (P2)
Pin
Signal
Pin
Signal
Pin
Signal
Pin
Signal
1
TX1+
35
TX1-
18
RX1+
52
RX1-
2
TX2+
36
TX2-
19
RX2+
53
RX2-
3
TX3+
37
TX3-
20
RX3+
54
RX3-
4
TX4+
38
TX4-
21
RX4+
55
RX4-
5
TX5+
39
TX5-
22
RX5+
56
RX5-
6
TX6+
40
TX6-
23
RX6+
57
RX6-
7
TX7+
41
TX7-
24
RX7+
58
RX7-
8
TX8+
42
TX8-
25
RX8+
59
RX8-
9
CSDB TX1+
43
reserved
26
GND
60
GND
10
CSDB TX1-
44
reserved
27
RX9+
61
RX9-
Note:
