Installation Configuring the CEI-820
CEI-100/CEI-200/CEI-x20 User’s Manual 11
Table 5. Mating Connector for P1
Manufacturer:
AMP
Connector:
787131-1
Metal backshell kit:
787233-1
Wire:
30 AWG
CEI-820 Transition Cable Pin Out
Table 6 defines the CONCEI-620 cable provided with each CEI-820. The
cable is approximately three feet in length. There is a Champ 0.8mm 50-
pin connector (AMP p/n 787131-1) at one end. The other end is a standard
subminiature-D, 50-pin plug connector (AMP p/n 205212-3 or equivalent).
Table 6. CEI-820 Transition Cable Pin Out
P1
D50
Signal
P1
D50
Signal
25
17
Discrete Input/Output 7
50
50
Discrete Input/Output 8
24
49
Discrete Input/Output 5
49
33
Discrete Input/Output 6
23
32
GND
48
16
GND
21
47
Discrete Input/Output 3
46
31
Discrete Input/Output 4
20
30
Discrete Input/Output 1
45
14
Discrete Input/Output 2
19
13
GND
44
46
GND
17
28
GND
42
12
GND
16
11
RX1A
41
44
RX1B
15
43
RX2A
40
27
RX2B
14
26
RX3A
39
10
RX3B
13
9
RX4A
38
42
RX4B
12
41
RX5A
37
25
RX5B
11
24
RX6A
36
8
RX6B
10
7
RX7A
35
40
RX7B
9
39
RX8A
34
23
RX8B
8
22
TX1A
33
6
TX1B
7
5
TX2A
32
38
TX2B
6
37
TX3A
31
21
TX3B
5
20
TX4A
30
4
TX4B
4
3
TX5A
29
36
TX5B
3
35
TX6A
28
19
TX6B
2
18
TX7A
27
2
TX7B
1
1
TX8A
26
34
TX8B
