CEI-100/200 ARINC Test Program Receive Menu
CEI-100/CEI-200/CEI-x20 User’s Manual 51
Channel 1 Running Triggering off HEX
Condor Engineering ARINC-429 Controller Rev 1.0
Main Menu
Enter receive mode
Toggle channel
Setup triggering
Toggle display format
Examine current buffer
Save buffer to disk
Return to main menu
Receive Menu
Enter a key to halt monitoring process.
Messages
Figure 30. Receive Menu
The following functions are performed using the Receive Menu:
 ENTER RECEIVE MODE
Starts receiving data on the current channel.
 TOGGLE CHANNEL
Cycles the current receive channel through the available receive
channels.
 SETUP TRIGGERING
Triggers on an ARINC data condition that is of interest. One
trigger condition is provided. The trigger condition can be used to
start or stop buffering. See “Triggering” for details.
 TOGGLE DISPLAY FORMAT
Toggles a data display between 'Normal' format, which includes
display fields for label and data, and 'ARINC' format, which
includes display fields for label, parity, SSM (Sign/Status Matrix),
data and SDI.
 EXAMINE CURRENT BUFFER
Presents the most recently stored data for examination.
 SAVE BUFFER TO DISK
Transfers the current buffer to a file. See “Receiving Messages”
for details.
