CEI-100/200 ARINC Test Program Setup Menu
CEI-100/CEI-200/CEI-x20 User’s Manual 46
Setup Menu
The menu for setting up the interface is shown in Figure 24. A message at
the bottom of the screen on the status line indicates whether a
configuration has been loaded at this time.
No configuration file active Radix HEX
Condor Engineering ARINC-429 Controller Rev 1.0
Main Menu
Initialize/test board
Select default radix
Save configuration
Restore configuration
Spawn to DOS shell
Return to main menu
Setup Menu
Figure 24. Setup Menu
This menu provides the functions that are used to set up the interface:
 INITIALIZE/TEST BOARD
This is a sub-function to initialize parameters on the installed
board. See “Board Setup” for details.
 SELECT DEFAULT RADIX
Selects the default radix for most input and output. Valid choices
are HEX or OCTAL.
 SAVE CONFIGURATION
Saves the current configuration, which includes all transmit
message data information; receive setup configuration, and all
board configuration information, including ARINC setup.
 RESTORE CONFIGURATION
Reloads a configuration saved via the above function. This can
also be done from the command line with the /C switch.
 SPAWN DOS SHELL
Spawn a DOS shell. Once in the shell, type EXIT to return to the
program.
