abaco systems CEI-520 - Transmit and Receive Operations

CEI-100/200 ARINC Test Program Transmit Menu
CEI-100/CEI-200/CEI-x20 User’s Manual 48
Board at D000, I/O 380 Xmit Rate 100K Recv Rate 100K Odd parity HEX
Condor Engineering ARINC-429 Controller Rev 1.0
Main Menu
Setup Menu
Toggle xmitter bit rate
Toggle receiver bit rate
Toggle parity
Execute self-test
Return to setup menu
Adapter Menu
External self-test
Internal self-test
Self-test Menu
Wrap-around data test RUNNING. Enter any key to halt.
Messages
Number of test runs: 5
Number of tests failed: 0
Self-test Summary
Figure 26. Self-test
Transmit Menu
The Transmit Menu is used to define a message to be transmitted, to select
between single or repeated transmission, and to start the transmission
process. The menu is shown in Figure 27.
Repeat Mode Stopped Radix HEX
Condor Engineering ARINC-429 Controller Rev 1.0
Main Menu
Define message
Repeat / Step
Start transmitting
Return to main menu
Transmit Menu
Figure 27. Transmit Menu
 DEFINE MESSAGE
This function defines an ARINC message and has it transmitted
on the 429 bus, once or at repetitive intervals. A message is
considered one or more ARINC words (32 bits) of the same label
sent out at the same time. A word comprises 8 bits for the label
