Installation Configuring the CEI-820
CEI-100/CEI-200/CEI-x20 User’s Manual 9
Signal
P1 Pin
P14 Pin
Signal
P1 Pin
P14 Pin
RX7A
10
27
RX7B
35
28
RX6A
11
29
RX6B
36
30
RX5A
12
31
RX5B
37
32
RX4A
13
33
RX4B
38
34
RX3A
14
35
RX3B
39
36
RX2A
15
37
RX2B
40
38
RX1A
16
39
RX1B
41
40
GND
17,19,23
41,47
GND
42,44,48
42,48
Discrete Input/Output 1
20
49
Discrete Input/Output 2
45
50
Discrete Input/Output 3
21
51
Discrete Input/Output 4
46
52
Discrete Input/Output 5
24
53
Discrete Input/Output 6
49
54
Discrete Input/Output 7
25
55
Discrete Input/Output 8
50
56
Discrete Input/Output 9
57
Discrete Input/Output 10
58
Discrete Input/Output 11
59
Discrete Input/Output 12
60
Discrete Input/Output 13
61
Discrete Input/Output 14
62
Discrete Input/Output 15
63
Discrete Input/Output 16
64
P1 is a 50-pin, Champ 0.8 mm receptacle connector. The AMP part
number is 787096-1.
Signal pairs “TXnA”/”TXnB” and “RXnA”/”RXnB” are the positive and
negative lines of an ARINC differential pair.
The discrete inputs and outputs share the same lines. There are a total
of 16 bi-directional discretes on the CEI-820, each of which can be
treated as an input or an output. For example, you may choose to use
discretes 1-4 as inputs and 5-16 as outputs.
Discrete inputs/outputs 9-16 are available only on the mezzanine
connector (P14).
Optional, non-ARINC 429 protocols are assigned to the following
channels for configurations that support them:
Protocol
Receive channels
Transmit channels
ARINC 573/717
Bipolar return-to-zero encoding
#1
#1
ARINC 573/717
Harvard bi-phase encoding
#1
#1
Since they use the same pins,
BPRZ & HBP encoding cannot
be used at the same time.
ARINC 561
See Table 4.
None
Notes:
