88 ACS550 User’s Manual
Parameters
1206 CONST SPEED 5 0…30000 rpm / 0.0…500.0 Hz 1 rpm / 0.1 Hz 01: 1500 rpm / 25.0 Hz
U1: 1800 rpm / 30.0 Hz
1207
CONST SPEED 6 0…30000 rpm / 0.0…500.0 Hz 1 rpm / 0.1 Hz 01: 2400 rpm / 40.0 Hz
U1: 2880 rpm / 48.0 Hz
1208
CONST SPEED 7 0…30000 rpm / 0.0…500.0 Hz 1 rpm / 0.1 Hz 01: 3000 rpm / 50.0 Hz
U1: 3600 rpm / 60.0 Hz
1209
TIMED MODE SEL 1=EXT/CS1/2/3, 2 = CS1/2/3/4 1 2 (CS1/2/3/4) !
Group 13: ANALOG INPUTS
1301
MINIMUM AI1 0.0…100.0% 0.1% 0.0%
1302
MAXIMUM AI1 0.0…100.0% 0.1% 100.0%
1303
FILTER AI1 0.0…10.0 s 0.1 s 0.1 s
1304
MINIMUM AI2 0.0…100.0% 0.1% 0.0%
1305
MAXIMUM AI2 0.0…100.0% 0.1% 100.0%
1306
FILTER AI2 0.0…10.0 s 0.1 s 0.1 s
Group 14: RELAY OUTPUTS
1401
RELAY OUTPUT 1 0…47, 52 1 1 (READY)
1402
RELAY OUTPUT 2 0…47, 52 1 2 (RUN)
1403
RELAY OUTPUT 3 0…47, 52 1 3 [FAULT(-1)]
1404
RO 1 ON DELAY 0.0…3600.0 s 0.1 s 0.0 s
1405
RO 1 OFF DELAY 0.0…3600.0 s 0.1 s 0.0 s
1406
RO 2 ON DELAY 0.0…3600.0 s 0.1 s 0.0 s
1407
RO 2 OFF DELAY 0.0…3600.0 s 0.1 s 0.0 s
1408
RO 3 ON DELAY 0.0…3600.0 s 0.1 s 0.0 s
1409
RO 3 OFF DELAY 0.0…3600.0 s 0.1 s 0.0 s
1410
RELAY OUTPUT 4 0…46, 52 1 0 (NOT SEL)
1411
RELAY OUTPUT 5 0…46, 52 1 0 (NOT SEL)
1412
RELAY OUTPUT 6 0…46, 52 1 0 (NOT SEL)
1413
RO 4 ON DELAY 0.0…3600.0 s 0.1 s 0.0 s
1414
RO 4 OFF DELAY 0.0…3600.0 s 0.1 s 0.0 s
1415
RO 5 ON DELAY 0.0…3600.0 s 0.1 s 0.0 s
1416
RO 5 OFF DELAY 0.0…3600.0 s 0.1 s 0.0 s
1417
RO 6 ON DELAY 0.0…3600.0 s 0.1 s 0.0 s
1418
RO 6 OFF DELAY 0.0…3600.0 s 0.1 s 0.0 s
Group 15: ANALOG OUTPUTS
1501
AO1 CONTENT SEL 99…159 1 103 (parameter 0103
OUTPUT FREQ)
1502
AO1 CONTENT MIN - - Defined by par. 0103
1503
AO1 CONTENT MAX - - Defined by par. 0103
1504
MINIMUM AO1 0.0…20.0 mA 0.1 mA 0.0 mA
1505
MAXIMUM AO1 0.0…20.0 mA 0.1 mA 20.0 mA
1506
FILTER AO1 0.0…10.0 s 0.1 s 0.1 s
1507
AO2 CONTENT SEL 99…159 1 104 (parameter 0104
CURRENT)
1508
AO2 CONTENT MIN - - Defined by par. 0104
1509
AO2 CONTENT MAX - - Defined by par. 0104
1510
MINIMUM AO2 0.0…20.0 mA 0.1 mA 0.0 mA
Code Name Range Resolution Default User S
