ACS550 User’s Manual 89
Parameters
1511 MAXIMUM AO2 0.0…20.0 mA 0.1 mA 20.0 mA
1512
FILTER AO2 0.0…10.0 s 0.1 s 0.1 s
Group 16: SYSTEM CONTROLS
1601
RUN ENABLE -6…7 1 0 (NOT SEL) !
1602
PARAMETER LOCK 0=LOCKED, 1 = OPEN, 2 = NOT SAVED 11 (OPEN)
1603
PASS CODE 0…65535 1 0
1604
FAULT RESET sEL -6…8 1 0 (KEYPAD)
1605
USER PAR SET CHG -6…6 1 0 (NOT SEL)
1606
LOCAL LOCK -6…8 1 0 (NOT SEL)
1607
PARAM SAVE 0=DONE, 1 = SAVE…10 (DONE)
1608
START ENABLE 1 -6…7 1 0 (NOT SEL) !
1609
START ENABLE 2 -6…7 1 0 (NOT SEL) !
1610
DISPLAY ALARMS 0=NO, 1 = YES 10 (NO)
1611
PARAMETER VIEW 0=DEFAULT, 1 = FLASHDROP 10 (DEFAULT)
Group 20: LIMITS
2001
MINIMUM SPEED -30000…30000 rpm 1 rpm 0 rpm !
2002
MAXIMUM SPEED 0…30000 rpm 1 rpm 01: 1500 rpm /
U1: 1800 rpm
!
2003
MAX CURRENT 0… 1.8 · I
2hd
0.1 A 1.8 · I
2hd
!
2005
OVERVOLT CTRL 0 = DISABLE, 1 = ENABLE 11 (ENABLE)
2006
UNDERVOLT CTRL 0 = DISABLE, 1 = ENABLE(TIME),
2 =
ENABLE
11 [ENABLE(TIME)]
2007
MINIMUM FREQ -500.0…500.0 Hz 0.1 Hz 0.0 Hz !
2008
MAXIMUM FREQ 0.0…500.0 Hz 0.1 Hz 01: 50.0 Hz /
U1: 60.0 Hz
!
2013
MIN TORQUE SEL -6…7 1 0 (MIN TORQUE 1)
2014
MAX TORQUE SEL -6…7 1 0 (MAX TORQUE 1)
2015
MIN TORQUE 1 -600.0…0.0% 0.1% -300.0%
2016
MIN TORQUE 2 -600.0…0.0% 0.1% -300.0%
2017
MAX TORQUE 1 0.0…600.0% 0.1% 300.0%
2018
MAX TORQUE 2 0.0…600.0% 0.1% 300.0%
Group 21: START/STOP
2101
START FUNCTION Vector control modes: 1, 2, 8
Scalar control mode: 1…5, 8
18 (RAMP) !
2102
STOP FUNCTION 1 = COAST, 2 = RAMP 11 (COAST)
2103
DC MAGN TIME 0.00…10.00 s 0.01 s 0.30 s
2104
DC HOLD CTL 0=NOT SEL, 1 = DC HOLD,
2=
DC BRAKING
10 (NOT SEL) !
2105
DC HOLD SPEED 0…360 rpm 1 rpm 5 rpm
2106
DC CURR REF 0…100% 1% 30%
2107
DC BRAKE TIME 0.0…250.0 s 0.1 s 0.0 s
2108
START INHIBIT 0=OFF, 1 = ON 10 (OFF)
2109
EMERG STOP SEL -6…6 1 0 (NOT SEL)
2110
TORQ BOOST CURR 15…300% 1% 100%
2112
ZERO SPEED DELAY 0.0 = NOT SEL, 0.1…60.0 s 0.1 s 0.0 s (NOT SEL)
2113
START DELAY 0.00…60.00 s 0.01 s 0.00 s
Code Name Range Resolution Default User S
