ACS550 User’s Manual 91
Parameters
2907 USER MWh TRIG 0.0…6553.5 MWh, 0.0 disables 0.1 MWh 0.0 MWh
2908
USER MWh ACT 0.0…6553.5 MWh 0.1 MWh 0.0 MWh
Group 30: FAULT FUNCTIONS
3001
AI<MIN FUNCTION 0…3 1 0 (NOT SEL)
3002
PANEL COMM ERR 1…3 1 1 (FAULT)
3003
EXTERNAL FAULT 1 -6…6 1 0 (NOT SEL)
3004
EXTERNAL FAULT 2 -6…6 1 0 (NOT SEL)
3005
MOT THERM PROT 0 = NOT SEL, 1 = FAULT, 2 = ALARM 11 (FAULT)
3006
MOT THERM TIME 256…9999 s 1 500 s
3007
MOT LOAD CURVE 50…150% 1 100%
3008
ZERO SPEED LOAD 25…150% 1 70%
3009
BREAK POINT FREQ 1…250 Hz 1 35 Hz
3010
STALL FUNCTION 0 = NOT SEL, 1 = FAULT, 2 = ALARM 10 (NOT SEL)
3011
STALL FREQUENCY 0.5…50 Hz 0.1 Hz 20 Hz
3012
STALL TIME 10…400 s 1 s 20 s
3017
EARTH FAULT 0 = DISABLE, 1 = ENABLE 11 (ENABLE) !
3018
COMM FAULT FUNC 0 = NOT SEL, 1 = FAULT, 2 = CONST SP 7,
3 =
LAST SPEED
10 (NOT SEL)
3019
COMM FAULT TIME 0…60.0 s 0.1 s 3.0 s
3021
AI1 FAULT LIMIT 0…100% 0.1% 0%
3022
AI2 FAULT LIMIT 0…100% 0.1% 0%
3023
WIRING FAULT 0 = DISABLE, 1 = ENABLE 11 (ENABLE) !
3024
CB TEMP FAULT 0 = DISABLE, 1 = ENABLE 11 (ENABLE)
Group 31: AUTOMATIC RESET
3101
NUMBER OF TRIALS 0…5 1 0
3102
TRIAL TIME 1.0…600.0 s 0.1 s 30 s
3103
DELAY TIME 0.0…120.0 s 0.1 s 0 s
3104
AR OVERCURRENT 0 = DISABLE, 1 = ENABLE 10 (DISABLE)
3105
AR OVERVOLTAGE 0 = DISABLE, 1 = ENABLE 10 (DISABLE)
3106
AR UNDERVOLTAGE 0 = DISABLE, 1 = ENABLE 10 (DISABLE)
3107
AR AI<MIN 0 = DISABLE, 1 = ENABLE 10 (DISABLE)
3108
AR EXTERNAL FLT 0 = DISABLE, 1 = ENABLE 10 (DISABLE)
Group 32: SUPERVISION
3201
SUPERV 1 PARAM 100 = NOT SELECTED, 101…159 1 103 (parameter 0103
OUTPUT FREQ)
3202
SUPERV 1 LIM LO --0
3203
SUPERV 1 LIM HI --0
3204
SUPERV 2 PARAM 100 = NOT SELECTED, 101…159 1 104 (parameter 0104
CURRENT)
3205
SUPERV 2 LIM LO --0
3206
SUPERV 2 LIM HI --0
3207
SUPERV 3 PARAM 100 = NOT SELECTED, 101…159 1 105 (parameter 0105
TORQUE)
3208
SUPERV 3 LIM LO --0
3209
SUPERV 3 LIM HI --0
Code Name Range Resolution Default User S
